Lycoming Adjustable Oil Pressure Relief Valve Assembly, 77808
Chỉ giao tại Úc. Phí vận chuyển tính khi thanh toán.
Toàn bộ chính sách vận chuyểnThông tin sản phẩm
Lycoming 77808 is an adjustable oil pressure relief valve assembly for Lycoming engines. Lycoming's Illustrated Parts Catalogs list it under Crankcase Related Parts, one per engine, for the (L)IO-360-M1A, IO-360-L2A, IO-360-B4A, AEIO-360-B1F and O-540-F1B5.
- Adjustable type: Lycoming's catalogue note says to select the relief valve spring so a minimum of three threads are exposed on the adjusting screw to allow field adjustment, with spring identification in Table of Limits SSP-1776 Part I
- The relief valve spring, ball and annular gasket are listed as separate items in the same Lycoming catalogues
Thông số kỹ thuật
